Allen-Bradley 1336 PLUS Selection Guide

1-2 PowerFlex® 700 and 700S Product Selection
Frame Selection
The following table is used to determine the frame size required based on
the desired Drive Type, Input Voltage and Horsepower.
Table 1.A PowerFlex 700 ad 700S Frame Selection
PowerFlex® 700 Frame Sizes
Drive
Type
Code
Input Voltage
Duty
Rating
0
(2.0 SF
20” Wide)
1
(2.0 SF
20” Wide)
2
(2.0 SF
20” Wide)
3
(3.0 SF
20” Wide)
4
(6.0 SF
20” Wide)
5
(6.0 SF
20” Wide)
6
(6.0 SF
25” Wide)
Q 230V AC ND - HP 0.5 - 1 2 - 7.5 10 15 - 20 25 - 30 40 - 50 60 - 75
HD - HP 0.33 - 0.75 1.5 - 5 7.5 10 - 15 20 - 25 30 - 40 50 - 60
380V AC ND - kW 0.75 - 4 7.5 - 11 15 - 18.5 22 - 37 45 55 - 75 90 - 132
HD - kW 0.55 - 3 5.5 - 7.5 11 - 15 18.5 - 30 37 45 - 55 75 - 110
460V AC ND - HP 0.5 - 7.5 10 - 15 20 - 25 30 - 50 60 75 - 100 125 - 150
HD - HP 0.33 - 5 7.5 - 10 15 - 20 25 - 40 50 60 - 75 100 - 125
575V AC ND - HP 0.5 - 10 10 - 15 20 - 25 30 - 50 60 75 - 100 125 - 150
HD - HP 0.75 - 7.5 7.5 - 10 15 - 20 25 - 40 50 60 - 75 100 - 125
R 310V DC ND - HP 0.5 - 1 2 - 7.5 10 15 - 20 25 - 30 40 - 50 60 75
HD - HP 0.33 - 0.75 1.5 - 5 7.5 10 - 15 20 - 25 30 - 40 50 - 60
512V DC ND - kW 0.75 - 4 7.5 - 11 15 - 18.5 22 - 37 45 55 - 75 90 - 132
HD - kW 0.55 - 3 5.5 - 7.5 11 - 15 18.5 - 30 37 45 - 55 75 - 110
620V DC ND - HP 0.5 - 7.5 10 - 15 20 - 25 30 - 50 60 75 - 100 125 - 150
HD - HP 0.33 - 5 7.5 - 10 15 - 20 25 - 40 50 60 - 75 100 - 125
775V DC ND - HP 0.5 - 10 10 - 15 20 - 25 30 - 50 60 75 - 100 125 - 150
HD - HP 0.75 - 7.5 7.5 - 10 15 - 20 25 - 40 50 60 - 75 100 - 125
PowerFlex® 700S Frame Sizes
Drive
Type
Code
Input
Voltage
Duty
Rating
1
(2.0 SF
20” Wide)
2
(2.0 SF
20” Wide)
3
(3.0 SF
20” Wide)
4
(6.0 SF
20” Wide)
5
(6.0 SF
20” Wide)
6
(6.0 SF
25” Wide)
9
(6.0 SF
30” Wide)
10
(6.0 SF
35” Wide)
(1)
S 230V AC ND - HP 0.5 - 7.5 10 15 - 20 25 - 30 40 - 50 60 - 75 NA NA
HD - HP 0.33 - 5 7.5 10 - 15 20 - 25 30 - 40 50 - 60 NA NA
380V AC ND - kW 0.75 - 11 15 - 18.5 22 - 37 45 55 - 75 90 - 132 132 - 160 (Future)
HD - kW 0.55 - 7.5 11 - 15 8.5 - 30 37 45 - 55 75 - 110 110 - 132 (Future)
460V AC ND - HP 0.5 - 15 20 - 25 30 - 50 60 75 - 100 125 - 150 200 - 250 (Future)
HD - HP 0.33 - 10 15 - 20 25 - 40 50 60 - 75 75 - 125 150 - 200 (Future)
575V AC ND - HP 0.5 - 15 20 - 25 30 - 50 60 75 - 100 125 - 150 150 - 200 (Future)
HD - HP 0.33 - 10 15 - 20 25 - 40 50 60 - 75 100 - 125 150 (Future)
T 310V DC ND - HP 0.5 - 7.5 10 15 - 20 25 - 30 40 - 50 60 - 75 NA NA
HD - HP 0.33 - 5 7.5 10 - 15 20 - 25 30 - 40 50 - 60 NA NA
512V DC ND - HP 0.75 - 11 15 - 18.5 22 - 37 45 55 - 75 90 - 132 132 - 160 (Future)
HD - HP 0.55 - 7.5 11 - 15 8.5 - 30 37 45 - 55 75 - 110 110 - 132 (Future)
620V DC ND - HP 0.5 - 15 20 - 25 30 - 50 60 75 - 100 125 - 150 200 - 250 (Future)
HD - HP 0.33 - 10 15 - 20 25 - 40 50 60 - 75 100 - 125 150 - 200 (Future)
775V DC ND - HP 0.5 - 15 20 - 25 30 - 50 60 75 - 100 125 - 150 150 - 200 (Future)
HD - HP 0.33 - 10 15 - 20 25 - 40 50 60 - 75 100 - 125 150 (Future)
(1)
Frame 10 is a 25 inch deep, flush-back enclosure.

Allen-Bradley 1336 PLUS Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Frequency	0-400 Hz
Frequency	50/60 Hz
Dimensions	Varies by model
Weight	Varies by model
Enclosure	NEMA 1
Output Current	Varies by model
Power Rating	Varies by model
Communication	RS-485
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Storage Temperature	-40 to 70°C (-40 to 158°F)
Humidity	5 to 95% non-condensing
Control Method	Sensorless Vector
