Allen-Bradley 1336 PLUS Selection Guide

1-4 PowerFlex® 700 and 700S Product Selection
Drive Duty Cycle
(1)
99ND Normal Duty
99HD Heavy Duty
Emissions
(1)
14EMA CE filter and common mode choke
(18)(19)(21)
14EMB CE filter and no common mode choke
(20)(21)
14EMB1 CE filter and external common mode choke
(22)
14EMN No CE filter and no common mode choke
(22)(23)
14EMN1 No CE filter and external common mode choke
(22)(23)
Documentation
(1)(16)
N No documentation
A English User Manual
E Quick Start Guide and CD
I/O Selection
(PowerFlex 700
Only)
(1)
14IOC Vector I/O, 24V
14IOD Vector I/O, 115V
Control (PowerFlex
700S Only)
(1)
14CIOA Phase II with expanded cassette, no Logix extras, no SynchLink™
14CIOB Phase II with expanded cassette, no Logix extras, with SynchLink
14CIOC Phase II with expanded cassette, with Logix extras, no SynchLink
(14)
14CIOD Phase II with expanded cassette, with Logix extras, with SynchLink
(14)
14CIOG Phase II slim cassette, no Logix extras, no SynchLink
14CIOH Phase II slim cassette, no Logix extras, with SynchLink
Configurations
(1)
ELC2SNN Phase II, no DriveLogix, no embedded comm.
ELC2SNE Phase II, no DriveLogix, EtherNet/IP embedded comm.
ELC2SNC Phase II, no DriveLogix, ControlNet embedded comm.
ELC2SEN Phase II, 5730 DriveLogix™, no embedded comm.
ELC2SEE Phase II, 5730 DriveLogix, EtherNet/IP embedded comm.
ELC2SEC Phase II, 5730 DriveLogix, ControlNet embedded comm.
Compact I/O
Cable
(17)
CIOL Drive to left bank expansion
CIOR Drive to right bank expansion
Feedback
(PowerFlex 700
Only)
(1)
14ENC Standard encoder
14ENCN No feedback PCB
Feedback
(PowerFlex 700S
Only)
(1)
14EN2 Second encoder feedback
(14)
14HEF Heidenhain feedback PCB
(13)
14HENC Hi-Resolution Stegmann resolver feedback PCB
(13)
14MDI Multi-Device Interface
(13)
14PN No feedback PCB
14RES Resolver feedback PCB
(13)
14SO Safe-Off (includes second encoder feedback)
(14)
Braking Option
(1)
16BI Braking IGBT included
16BNI Braking IGBT not included
Braking Resistor
(1)
14BR Braking resistor included
14BRN Braking resistor not included
14BRE Braking resistor, external
Enclosure Options
MCC Bottom
Support
(1)(5)
XBC 1.5 inch high base channels
XBSM Bottom support angle multi-section
Options Available to All Units:
Option Option Code Description

Allen-Bradley 1336 PLUS Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Frequency	0-400 Hz
Frequency	50/60 Hz
Dimensions	Varies by model
Weight	Varies by model
Enclosure	NEMA 1
Output Current	Varies by model
Power Rating	Varies by model
Communication	RS-485
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Storage Temperature	-40 to 70°C (-40 to 158°F)
Humidity	5 to 95% non-condensing
Control Method	Sensorless Vector
