Allen-Bradley 1395 - Page 102

A-12 Parameter List/Record
Table A.M Digital Reference Adapter Configuration Parameters
Digital Ref
Adapter I/O
Parameter
Port A/B
Port Configuration Parameters A/B
Linked to
Parameter DescriptionParameter Value
PLC
Address
Digital In #1 400/300 583/ BIT
405/305 533
Digital In #2 400/300 584/ BIT
405/305 534
Digital In #3 400/300 585/ BIT
405/305 535
Digital In #4 400/300 586/ BIT
405/305 536
Digital In #5 400/300 587/ BIT
405/305 537
Digital In #6 400/300 588/ BIT
405/305 538
Digital In #7 400/300 589/ BIT
405/305 539
Digital In #8 400/300 590/ BIT
405/305 540
Digital In #9 400/300 591/ BIT
405/305 541
Digital In #10 400/300 592/ BIT
405/305 542
Digital Out #1 450/350 558/ BIT
454/354 508
Digital Out #2 450/350 559/ BIT
454/354 509
Digital Out #3 450/350 560/ BIT
454/354 510
Digital Out #4 450/350 561/ BIT
454/354 511
Digital Out #5 450/350 562/ BIT
454/354 511
Analog In #1 401/301 550/ ADC SCALE
500
551 ADC OFFSET
501
552 AN GAIN
502
553 AN OFFSET
503
Analog In #2 402/302 554/ ADC SCALE
504
555/ ADC OFFSET
505
556/ AN GAIN
506
557/ AN OFFSET
507
Analog Out #1 451/351 575/ DAC SCALE
525
576/ DAC OFFSET
526
