Allen-Bradley 1398 ULTRA Plus Series User Manual

Publication 1398-5.1 — January 2000
Install the ULTRA Plus PDM Components 2-9
Figure 2.4
Three Phase Transformer Outline Diagram
A MAX
1
1
B MAX
.012 REF
F REF
C MAX
D ±0.06
G REF
E ±0.06
B-C
19866,20625
A00761
TM
__ __
C1 REDRAWN
2
1
SECONDARY
CONNECTIONS
PRIMARY
CONNECTIONS
CONNECTION INSTRUCTIONS
0.25-20 GROUND STUD
(TRANSFORMER CHASSIS)
8.0 MIN CLEARANCE
RECOMMENDED FOR
ACCESS TO WIRING
0.56 ±0.03 DIA THRU (4)
OVERALL DIMENSIONS
F
G
PRIMARY
SECONDARY
3.50
2.38
2.38
3.25
1.15
1.36
1.30
1.81
5-40
6-32
6-32
8-32
6-32
8-32
10-32
10-32
3
6
12
18
12.50
15.25
15.25
22.50
6.50
6.50
8.50
9.00
9.50
12.50
13.25
18.25
5.50
10.50
10.50
16.00
4.20
3.78
5.90
5.38
A
B
CDE
RELIANCE MOTION CONTROL
TRANSFORMER PART NO.
KVA
RATING
0020-5091-001
0020-5091-002
0020-5091-003
0020-5091-004
MOUNTING HOLES LOCATION SCREW SIZES
9101-0131
.XXX±.005
DECIMALS.XX±.010
FRACTIONS:±1/64"
DO NOT SCALE DRAWING
ANGLES ±1ANGLES ˚
TOLERANCE ON:
FILLETS AND ROUNDS .02 R MAX
BREAK ALL EDGES .02 MAX
DIMENSIONS ARE IN INCHES
DATE DATE
D
PART NO.
DWG SIZE SHEETSCALE
1:1
of
REV ECO CHKRDATEREVISION DESCRIPTIONBY
DESIGN ENGRDRAWN BY
8-5-88
8-88 BC JH
PART NO.
UNLESS OTHERWISE SPECIFIED
9101-0131
2-5-87
11
DIAG,OUTLINE,XFMR,BRU-500/IQ5000
JH
BCB
16383 A
RELEASED
2
1
RING OR SPADE LUG CONNECTORS (NOT PROVIDED) ARE REQUIRED FOR WIRING
CONNECTIONS TO TRANSFORMER TERMINAL STRIPS.TERMINAL STRIP SCREW
SIZES ARE LISTED IN THE DIMENSION CHART.
USE LUGS DESIGNED FOR #6 SCREW MOUNTING.
NOTES:
