Change battery
Sostituire batterie
Batterie ersetzen
Remplacer batteries
Sustituir baterías
PROCEDURA DI CONTROLLO
- CONTROLLO LED:
tutti i led del relè si
devono accendere
- ULTIMA INDICAZIONE DI TRIP:
se presente nella memoria
del relè
- LED: resta acceso finchè
140G-ELTT Tester è connessa
al relè
- PRONTO PER TRIP
1
Green
Verde
Grün
Vert
Verde
Red
Rosso
Rot
Rouge
Rojo
Device ON
Dispositivo acceso
Einrichtung eingeschaltet
Dispositif allumé
Dispositivo encendido
CLACK
4
3
2
DIAGNOSTIC PROCEED
- UNIT CHECK LED:
all the leds in the relay
must come on
- LAST TRIP INDICATION:
if present in the relay's
data store
- LED: remains on for
as long as the 140G-ELTT
Tester is connected to
the relay
- READY TO TRIP
DIAGISTIKABLAUF
- EINEITHSPRUF-LED:
Alle LEDs des Relais müssen
aufleuchten
- ANGABE DER LETZTEN AUSLOSUNG:
Wenn im Speicher des Relais
vorhanden.
- LED: Bleibt angeschaltet,
bis die Einheit 140G-ELTT Tester
an die Relais angeschlossen ist.
- AUSLOSEBEREIT
PROCEDIMIENTO DIAGNOSTICO
- LED CONTROL UNIDAD: todos los
led del relé se deben
encender
- INDICACION ULTIMA ACTUACION:
si está presente en la memoria
del relé
- LED: queda encendido
mientras la 140G-ELTT Tester
permanezca conectada con el relé
- LISTO PARA LA ACTUACION
PROCÉDURE DE DIAGNOSTIC
- UNIT CHECK LED : toutes les
diodes du relais doivent
s'allumer
- LAST TRIP INDICATION :
si présente dans la mémoire
du relais
- LED: la DIODE reste
allumée tant que 140G-ELTT
Tester est connectée au relais
- READY TO TRIP
TRIP
LED TRIP TEST DEVICE
140G-ELTT
(ordered separately)
