Chapter 4 Data Access Control
Configure Constant Tags
This section describes the various ways a constant attribute can be configured.
Set Up a Constant in the New Tag Dialog Box
Follow these steps to configure a tag as a constant on the New Tag dialog box.
1. On the Controller Organizer, right-click Controller Tags and choose New
Tag .
The New Tag Dialog Box appears.
2. From the Type menu, choose a tag type.
3. Check Constant.
4. Click OK.
See “Constant Checkbox Availability”
on page 81 for considerations.
Configure a Constant in the Tag Properties Dialog Box
Follow these steps to designate a tag as a constant on the Tag Properties
dialog box.

Allen-Bradley 1768-L43S CompactLogix 5343S Specifications

General

Controller Type	CompactLogix
Input Voltage	24V DC
Programming Software	RSLogix 5000
Motion Control	Yes
Safety Capable	Yes
Ethernet Ports	1
I/O Modules Supported	1769 Compact I/O
Communication Ports	Ethernet, Serial
Operating Temperature	0°C to 60°C (32°F to 140°F)
Certifications	CE, UL, cUL
