Chapter 2 Install the CompactLogix 5370 L2 Controller
118.00 mm
(4.65 in.)
35.00 mm
(1.38 in.)
105 mm
(4.13 in.)
140.00 mm
(5.51 in.)
18.00 mm
(0.71 in.)
126.6 mm
(4.98 in.)
25.00 mm
(0.98 in.)
