10 USB-to-DeviceNet Cable
Rockwell Automation Publication 1784-IN046D-EN-P - April 2011
Status Indicators
The following table describes the cable status indicators.
Status Indicators
Indicator Status Description
USB Green The cable is configured, but no network traffic
is present.
Flashing green Network traffic is present.
Off Unable to transfer data:
• Disconnected from host.
• In one of the following states:
– Default
– Powered
– Address
– Suspend
USB
Network
Status
Module
Status
