Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 141
Accessories and Dimensions Appendix B
Figure 21 - PowerFlex 400 Frame F Drive
Dimensions are in millimeters and (inches)
137.5 (5.41)
287.5 (11.32)
370.0 (14.57)
55.0 (2.17)
169.0
(6.65)
228.5
(9.00)
199.0
(7.83)
∅ 74.8
(2.94)
∅ 22.0
(0.87)
381.0 (15.00)
381.0 (15.00)
425.0 (16.73)
∅ 13.0
(0.51)
850.0
(33.46)
678.0
(26.69)
647.5
(25.49)
264.0 (10.39)
165.8 (6.53)
280.0 (11.02)
