168 Rockwell Automation Publication 22C-UM001J-EN-E - January 2017
Appendix D Application Notes
IMPORTANT If using auxiliary motor control, ensure that wiring and parameter
configuration are correct before wiring contactor outputs. All relays on the
Auxiliary Relay Card will energize on power-up by default. Failure to verify
proper wiring and parameter configuration can result in improper motor
operation or drive damage.
