1-3 4 5 6-8 9 10 11 12
22C – D 038 A 1 0 3
Drive Dash Voltage Rating Rating Enclosure HIM Emission Class Comm Slot
Code Drive
22C PowerFlex 400
Code Voltage Ph.
B 240V AC 3
D 480V AC 3
Output Current @ 200...240V 60Hz Input Output Current @ 380...480V Input
Code Amps kW HP Frame Code Amps kW HP Frame
012 12 2.2 3.0 C 6P0 6.0 2.2 3.0 C
017 17.5 3.7 5.0 C 010 10.5 4.0 5.0 C
024 24 5.5 7.5 C 012 12 5.5 7.5 C
033 33 7.5 10 C 017 17 7.5 10 C
04949 1115D 02222 1115C
06565 1520D 03030 1520C
075 75 18.5 25 D 038 38 18.5 25 D
09090 2230D 04545.5 2230D
120 120 30 40 E 060 60 30 40 D
145 145 37 50 E 072 72 37 50 E
088 88 45 60 E
105 105 55 75 E
142 142 75 100 E
170 170 90 125 F
208 208 110 150 F
260 260 132 200 G
310 310 160 250 G
370 370 200 300 H
460 460 250 350 H
Code Enclosure
N Panel Mount - IP20/UL Open-Type
(1)
A Panel Mount - IP30/NEMA 1/UL Type 1
(2)
F Flange Mount - IP20/UL Open Type
(3)
Code Interface Module
1 Fixed Keypad
Code Rating
0 Not Filtered
Code Version
3RS485
(1) Frame C drives only available with IP20/UL Open-Type enclosure. Field installed conversion kit available to achieve IP30/NEMA 1/UL Type 1 rating.
(2) Frame D, E, F, G and H drives only available with IP30/NEMA 1/UL Type 1 enclosure.
(3) Frame C drives only.
Additional accessories, options and adapters are available. See Appendix B for details.
