Visit our website: www.ab.com/catalogs
Bulletin 900-TC
Single-Loop Temperature/Process Controller
13
Bulletins 900-TC8, 900-TC16, and 900-TC32, Continued
Weight (includes carton)
900-TC8 Approx. 360 g (12.7 oz.) with mounting bracket
900-TC16 Approx. 160 g (5.6 oz.) with mounting bracket
900-TC32 Approx. 160 g (5.6 ounces)
900-TC8232, COM, EIM Approx. 20 g (0.7 ounces)
900-TC16COM, EIM Approx. 35 g (1.2 ounces)
Ambient Temperature –10…+55 °C (with no condensation or icing)
Ambient Humidity 25…85%
Storage Temperature –25…+65 °C (with no condensation or icing)
Insulation Resistance
20 MΩ min. (at 500V DC)
Dielectric Strength 2300V AC, 50 or 60 Hz for 1 min. (between terminals with different charge)
Maximum Operating Vibration 10…55 Hz, 20 m/s
2
(2 G) for 10 minutes each in X, Y, and Z directions
Maximum Shock Operating 100 m/s
2
(10 G), 3 times each in X, Y, and Z directions.
Protective Structure
Front panel: Type 4X (UL 50)
9 IP66 (IEC61010-1)
Rear case: IP20, Terminals: IP00
Installation Environment Installation category II, pollution class 2 (IEC 61010-1 compliant)
Memory Protection EEPROM (non-volatile memory) (number of writes: 100 000)
EMC
EMI EN 61326
Radiated Interference Electromagnetic
Field Strength
EN 55011 Group 1, class A
Noise Terminal Voltage EN 55011 Group 1, class A
EMS EN 61326
ESD Immunity EN 61000-4-2
Electromagnetic Field Immunity EN 61000-4-3
Burst Noise Immunity EN 61000-4-4
Conducted Disturbance Immunity EN 61000-4-6
Surge Immunity EN 61000-4-5
Power Frequency Magnetic Field
Immunity
EN 61000-4-8
Voltage Dip/Interrupting Immunity EN 61000-4-11
Conformed Standards
General/Environmental Ratings
Conforms to EN61010-1, IEC 61010-1, and VDE 0106/part 100 (finger
protection) when the terminal cover is installed, Pollution Level 2, Overcurrent
Category II
Technical/Control Ratings
Influence of Ambient
Temperature and Line
Voltage
y R, S, B, W, PL II Thermocouple Inputs: ±1% of PV or ±10°C, whichever is great, ±1 digit max.
y Other Thermocouple Inputs: ±1% of PV or ±4°C, whichever is greater ±1 digit max. Note: For a Type-K thermocouple for -100°C
or less ±10°C
y RTD Sensors: ±1% of PV or ±2°C, whichever is greater. ±1 digit max.
y Analog Inputs: ±1% of full scale ±1 digit max.
Hysteresis (Controller with
Temperature Inputs)
0.1…999.9 EU (in units of 0.1 EU)
³
Hysteresis (Controller with
Analog Inputs)
0.01 to 99.99% FS (in units of 0.01% Full Scale)
Proportional Band (P)
Controller with Temperature
Inputs
0.1…999.9 EU (in units of 0.1 EU)
³
Proportional Band Controller
with Analog Inputs
0.1 to 999.9% FS ( in units of 0.1% FS)
Integral Time (I) 0…3999 s (in units of 1 s)
Derivative Time (D)
0…3999 s (in units of 1 s)a
Control Period 0.5, 1…99 s (in units of 1 s)
Manual Reset Value 0.0…100.0% (in units of 0.1%)
Alarm Setting Range –1999…+9999 (decimal point position depends on input type)
Sampling Period 250 or 500 ms (900-TC8 or 900-TC16), 500 ms (900-TC32)
Other Functions According to Controller model
³ Engineering Unit (EU) is used as the unit after scaling. For a temperature sensor, the EU is °C or °F.
a When Robust Tuning (RT) is on, the differential is is 0.0... 999.9 in units of 0.1 sec.
Conditions: Ambient temperature: -10°C to 23°C to 55°C. Voltage Range: -15% to +10% of rated voltage.
9 The temperature controller is mounted on the flat surface of an enclosure that is rated and marked "Type 4X for Indoor Use Only"
Specifications, Continued
