32 PanelView Component HMI Terminals
Publication 2711C-IN001H-EN-P - July 2014
Temperature, surrounding, max 50 °C (122 °F)
Heat dissipation
C200 and C300
C400
C600
C1000
16 BTU/hr
24 BTU/hr
32 BTU/hr
58 BTU/hr
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% noncondensing
Vibration IEC 60068-2-6 (Test Fc, Operating):
2 g @ 10…500 Hz
Shock, operating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
15 g @ 11 ms
Shock, nonoperating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
30 g
Emissions CISPR 11:
Group 1, Class A
ESD Immunity IEC 61000-4-2:
4 kV contact discharges
8 kV air discharges
Radiated RF Immunity IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
3V/m with 1 kHz sine-wave 80% AM from 1400…2000 MHz
1V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
EFT/B Immunity IEC 61000-4-4:
±2 kV @ 5 kHz on power ports
±1 kV @ 5 kHz on communication ports
Surge Transient Immunity IEC 61000-4-5:
±500V line-line(DM) and ±1 kV line-earth(CM) on DC power ports
±1 kV line-earth(CM) on communication ports
Conducted RF Immunity IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Certifications
Certifications (when product is
marked)
(1)
Value
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File
E113724.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S.
and Canada. See UL File E10314. - For 2711C-T4T only
CE European Union 2004/108/EC EMC Directive, compliant with:
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
Environmental Specifications
Attribute Value
