14 Rockwell Automation Publication 2711P-IN001J-EN-P - April 2018
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules
Product Dimensions
The table provides product dimensions for the terminals including depth dimensions for the:
• base configured unit (display module and logic module).
• base configured unit with communication module.
The illustration shows product dimensions for the PanelView Plus and PanelView Plus Compact
1000 touch only terminals. The other size terminals look similar. Measurements are in mm (in.).
Terminal Type
Height, Approx.,
mm (in.)
Width,
Approx.,
mm (in.)
Depth, Approx., mm (in.)
700 Keypad or Keypad and Touch 193 (7.58) 290 (11.40)
55 (2.18)
display to logic module
83 (3.27)
display to comm module
700 Touch Screen 179 (7.04) 246 (9.68)
1000 Keypad or Keypad and Touch 248 (9.77) 399 (15.72)
1000 Touch Screen 248 (9.77) 329 (12.97)
1250 Keypad or Keypad and Touch 282 (11.12) 416 (16.36)
1250 Touch Screen 282 (11.12) 363 (14.30)
1500 Keypad or Keypad and Touch 330 (12.97) 469 (18.46) 65 (2.55)
display to logic module
93 (3.65)
display to comm module
1500 Touch Screen 330 (12.97) 416 (16.36)
