Rockwell Automation Publication 2711P-IN001J-EN-P - April 2018 27
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules
Startup Information Messages
Startup information messages display in a specific sequence on the terminal during startup and
typically display for a few seconds. These messages do not require that you perform any action.
Message # Message Description
37 Video Initialized Configures and initializes the graphics video system.
30 Watchdog Test Tests the watchdog circuitry to verify system integrity.
1 RAM Test Tests the RAM memory.
31 Stuck Key Checks the integrity of the function key hardware.
31.5 Stuck Touch Checks the integrity of the touch screen hardware.
32 Battery Test Checks the integrity of the battery hardware.
2.5 Registry Search
Locates and loads the most recent, valid registry. Multiple copies of the registry are
maintained. If power is lost during a registry update, a valid registry is available
the next time power is applied to the terminal.
2Image Search
Checks for a new OS firmware upgrade on the external CompactFlash card and the
serial port.
50 External CF
Transfers a new OS firmware upgrade from the external CompactFlash card to the
terminal. Message may display for several minutes.
23 Internal CF
Programs the OS firmware just downloaded into the internal flash memory.
Message may display for several minutes.
24 CRC Check Checks the integrity of the OS firmware.
28 Starting System Launches the operating system (OS).
29 System Check ### Internal file system integrity check (### is percent progress indicator).
29.1 System Check Internal file system integrity check disabled. Contact technical support.
