Allen-Bradley PowerFlex 20-750-S1 User Manual

Rockwell Automation Publication 750-IN001O-EN-P - October 2014 137
Lift and Mount the Drive Chapter 3
Adjust Roll-Out Cart Reach
Figure 85 - Reach Position A
Figure 86 - Reach Position B
ATTENTION: A tip over hazard exists. To guard against death, serious personal
injury, and/or equipment damage, verify the Drive Stop (see Figure 84
) is in the
same position as the corresponding threaded leveling studs. The weight of the
drive must be evenly distributed over the cart wheels.
78
(3.1)
142
(5.6)
