Allen-Bradley PowerFlex 700AFE Installation Instructions

48 Rockwell Automation Publication 750-IN100B-EN-P - July 2017
Chapter 3 Prepare for Installation
Frame 10 Bus Supplies Top, Front, and Bottom Views - Dimensions are mm (in.)
See page 51 for optional entry wire bay dimensions.
83
(3.3)
2335 (91.9) 1800 (70.9)
600
(23.6)
36
(1.4)
535
(21.1)
IP21, UL Type 1
2132
(83.9)
IP54, UL Type 12
2291
(90.2)
IP21, UL Type 1
676
(26.6)
IP54, UL Type 12
721
(28.4)
2406
(94.7)
1000
(39.4)
800
(31.5)
0 (0)
1735 (68.3) 1000 (39.4)
935 (36.8)
450
(17.7)
45
(1.8)
200
(7.9)
200
(7.9)
230
(9.1)
186
(7.3)
1481
(58.3)
200
(7.9)
726
(28.6)
473
(18.6)
45
(1.8)
Signal Cables - Top Entry
Mounting Holes
Input Power Cables - Bottom Entry
Signal Cables - Bottom Entry
Power Bay
Power BayInput Bay
