Chapter 3 Prepare for Installation
Frame 12 Bus Supplies Top, Front, and Bottom Views - Dimensions are mm (in.)
See page 51
for optional entry wire bay dimensions.
83
(3.3)
3206
(126.6)
1000
(39.4)
800
(31.5)
0 (0)
1735 (68.3)
600
(23.6)
36
(1.4)
535
(21.1)
IP21, UL Type 1
2132
(83.9)
2291
(90.2)
IP21, UL Type 1
676
(26.6)
721
(28.4)
1000 (39.4)
935 (36.8)
450
45
(1.8)
200
(7.9)
200
(7.9)
230
(9.1)
186
(7.3)
1481
45
(1.8)
800
(31.5)
2535 (99.8)
1800 (70.9)
Signal Cables - Top Entry
Mounting
Holes
Input Power Cables - Bottom Entry
Signal Cables - Bottom Entry
Power BayInput Bay Power Bay Power Bay
