Allen-Bradley PowerFlex 700AFE Installation Instructions

62 Rockwell Automation Publication 750-IN100B-EN-P - July 2017
Chapter 4 Mechanical and Electrical Installation
Figure 19 - Frame 8 Drives
Figure 20 - Frame 9 Drives
Module Type Remove Position No. Shipping Split Section
LCL filter module LCL0 Section 1 of 1
Line side converter L0
Motor side inverter M0
Module Type Remove Position No. Shipping Split Section
Line side converter L0, L1 Section 1 of 1
Motor side inverter M0, M1 Section 1 of 1
LCL0 L0 M0
M0L0 L1 M1
