Allen-Bradley PowerFlex 700AFE Installation Instructions

Rockwell Automation Publication 750-IN100B-EN-P - July 2017 69
Mechanical and Electrical Installation Chapter 4
Figure 31 - Frame 10 Common Bus Inverter
Figure 32 - Frame 11 Common Bus Inverter
Module Type Remove Position No. Shipping Split Section
Motor side inverter M0, M1, M2 Section 1 of 1
Module Type Remove Position No. Shipping Split Section
Motor side inverter M0, M1, M2, M3 Section 1 of 1
M1 M2M0
M1M0
M3M2
