Allen + Roth TPPER9137 - Assembly Step 2: Beam Assembly; Connect Beams and Add Ferrules

ASSEMBLY INSTRUCTIONS
2.1. Insert the connectors (E1) to the beams (C1), secure with bolts (AA) and plastic washers (FF),
tighten with wrench (JJ). Place cap (HH) on the bolt heads.
2.2. Attach the ferrule (F1) to the beam assemblies (C1/E1).
2.3. Attach the beams (C2) to the beam assemblies (C1/E1/F1) and secure with bolts (AA) and
plastic washers (FF), tighten with wrench (JJ). Place cap (HH) on the bolt heads.
AA
FF
HH
C1
C1
C1
F1
E1
E1
C2
C2
C1
F1
AA
FF
HH
2 Hardware Used
x6
x6
AA
FF
C2
C1
F1
AA
FF
HH
x1
JJ
x6
HH
