Allen + Roth TPPER9137 - Assembly Step 3: Sidewall Rods; Attach Sidewall Rods to Beams

3. Attach the sidewall rod (J) to the beam (C1/C2), secure with bolts (AA) and plastic washers (FF),
tighten with wrench (JJ). Place cap (HH) on the bolt heads.
J
AA
FF
F1
HH
AA
FF
HH
C1
C1
J
J
J
J
C2
C2
C2
J
ASSEMBLY INSTRUCTIONS
3 Hardware Used
x8
x8
AA
FF
x1
JJ
x8
HH
