allen AR16 - 13 HP Honda Engine with Recoil & Electric Start (AR16), Illustration & Parts List

SECTION 4
PARTS
055838Page 100
ITEM PART # DESCRIPTION QTY
1
EN0600 13 HP Honda Engine with Recoil Start 1
EN1700 13 HP Honda Engine with Electric Start with Recoil Backup 1
2 32103-02 Bolt Assembly (3/8” NC HHCS x 1-3/4” Long with (1) SAE Flat washer, (1) USS Flat Washer and (1) Lock Nut 4
3 45048-05 Throttle Stop Bolt Retaining Nut M5 x 0.8 Hex Nut Plated 1
4 32103-15 Heat Shield 1
5 45048-06 Key (1/4” SQ x 1-3/4” Long) 1
4.11 - 13HP Honda Engine with Recoil &
Electric Start (AR16), Illustration & Parts
List
