GS950 PS Series | Gigabit WebSmart PoE+ Edge Switches
PRODUCT WIDTH DEPTH HEIGHT WEIGHT MTBF (HOURS)
AT-GS950/10PS
330 mm (13 in) 200 mm (7.9 in) 44 mm (1.7 in) 1.9 Kg (4.20 lbs) >250,000
AT-GS950/16PS
430 mm (17 in) 250 mm (9.8 in) 44 mm (1.7 in) 3.56 Kg (7.85 lbs) >250,000
AT-GS950/48PS
440 mm (17.32 in) 430 mm (17 in) 44 mm (1.7 in) 6.62 Kg (14.60 lbs) >250,000
PRODUCT
MAX POWER
CONSUMPTION
MAX HEAT
DISSIPATION
NOISE VOLTAGE FREQUENCY
AT-GS950/10PS
13.58W 316.107 (BUT/hr) Fanless 100-240V AC 50-60Hz
AT-GS950/16PS
21.8W 779.185 (BUT/hr)
Low-speed 33 dB
High-speed 47.1 dB
100-240V AC 50-60Hz
AT-GS950/48PS
55.5W 1520.86 (BUT/hr)
Low-speed 38.3 dB
High-speed 51.6 dB
100-240V AC 50-60Hz
POWER SUPPLY UNIT
POE POWER AVAILABLE
MAXIMUM POE PORTS SUPPORTED
IEEE 802.3af CL ASS 2 IEEE 802.3af CL ASS 3 IEEE 802.3at CLASS 4
AT-GS950/10PS
75W 8 4 2
AT-GS950/16PS
185W 16 12 6
AT-GS950/48PS
370W 24 24 12
PRODUCT SWITCHING CAPACITY FORWARDING RATE
AT-GS950/10PS
20Gbps 14.88Mpps
AT-GS950/16PS
32Gbps 23.80Mpps
AT-GS950/48PS
96Gbps 71.42Mpps
Specifications
Performance
14,880pps for 10Mbps Ethernet
148,800pps for 100Mbps Ethernet
1,488,000pps for 1000Mbps Ethernet
MAC addresses 8,000
VLAN ID’s available 4,000
Max VLANs 256
Packet buffer 1MB
DRAM 64MB
Flash 16MB
Interface Connections
10/100/1000T RJ-45
SFP 100TX, 100FX, 1000T,
1000SX or 1000LX
Environmental Compliance
RoHS
Eu-RoHS
China RoHS
WEEE
MTBF
263,000 hours
Telcordia SR-332
Environmental Specifications
Operating temperature: 0ºC to 40ºC (32ºF to 104ºF)
Non-operating temperature: -25ºC to 70ºC
(-13ºF to 158ºF)
Operating humidity: 5% to 90% non-condensing
Storage humidity: 5% to 95% non-condensing
Vibration: IEC 68-2-36
Shock: IEC 68-2-29
Drop: IEC 68-2-32
Flammability: UL94V-0
Technical Specifications
Wall-mount or desktop
All units come with wall /19” rack-mount brackets
Standards and Compliance
IEEE 802.3 CSMA/CD IEEE 802.3i 10T
IEEE 802.3 u 100TX
IEEE 802.3z 1000SX /L X
IEEE 802.3z/ab 1000T
IEEE 802.3x Flow control
IEEE 802.1p Prioritization (four queues)
IEEE 802.1x Authentication
IEEE 802.1x Local authentication server
(MD5)
IEEE 802.1x Remote authentication
through RADIUS
IEEE 802.1x Dynamic VLAN assignment
IEEE 802.1x MAC-based authentication
IEEE 802.1x RADIUS
IEEE 802.1d Bridging
IEEE 802.3ad Link aggregation
IEEE 802.3ad Port trunking and LACP
IEEE 802.1Q Tagged VLAN
IEEE 802.1d Spanning-Tree
IEEE 802.1w Rapid Spanning-
Tree
IEEE 802.1s Multiple Spanning-Tree
Electrical/Mechanical Approvals
UL60950-1 2nd edition (UL)
FCC/EN55022/CISPR 22 Class A
VCCI Class A
C-Tick
EN60950 (TUV)
EN55024
CE Mark
CSA / cUL
Physical Specifications and MTBF Figures
Power and Noise Characteristics
Power over Ethernet Port Support
Product Contents
Switch unit
Rack-mount brackets and screws
Power cord
Rubber feet
