Allied Telesis x510 Series Product Information

x510 Series | Stackable Gigabit Switches
Physical Specifications
Power and Noise Characteristics
*GSX model will be available in the near future
*GSX model will be available in the near future Noise: tested to ISO7779; front bystander position
Standards and Protocols
AlliedWare Plus Operating System
Version 5.4.3 - 1.4
Authentication
RFC 1321 MD5 Message-Digest algorithm
RFC 1828 IP authentication using keyed MD5
Encryption
FIPS 180-1 Secure Hash standard (SHA-1)
FIPS 186 Digital signature standard (RSA)
FIPS 46-3 Data Encryption Standard (DES and 3DES)
Ethernet
IEEE 802.1AX Link aggregation (static and LACP)
IEEE 802.2 Logical Link Control (LLC)
IEEE 802.3 Ethernet
IEEE 802.3ab 1000BASE-T
IEEE 802.3ad Static and dynamic link aggregation
IEEE 802.3ae 10 Gigabit Ethernet
IEEE 802.3af Power over Ethernet (PoE)
IEEE 802.3at Power over Ethernet plus (PoE+)
IEEE 802.3az Energy Efficient Ethernet (EEE)
IEEE 802.3u 100BASE-X
IEEE 802.3x Flow control – full-duplex operation
IEEE 802.3z 1000BASE-X
IPv4 Features
RFC 768 User Datagram Protocol (UDP)
RFC 791 Internet Protocol (IP)
RFC 792 Internet Control Message Protocol (ICMP)
RFC 793 Transmission Control Protocol (TCP)
RFC 826 Address Resolution Protocol (ARP)
RFC 894 Standard for the transmission of IP datagrams
over Ethernet networks
RFC 919 Broadcasting Internet datagrams
RFC 922 Broadcasting Internet datagrams in the
presence of subnets
RFC 932 Subnetwork addressing scheme
RFC 950 Internet standard subnetting procedure
RFC 951 Bootstrap Protocol (BootP)
RFC 1027 Proxy ARP
RFC 1035 DNS client
RFC 1042 Standard for the transmission of IP datagrams
over IEEE 802 networks
RFC 1071 Computing the Internet checksum
RFC 1122 Internet host requirements
RFC 1191 Path MTU discovery
RFC 1256 ICMP router discovery messages
RFC 1518 An architecture for IP address allocation with
CIDR
RFC 1519 Classless Inter-Domain Routing (CIDR)
RFC 1542 Clarifications and extensions for BootP
RFC 1591 Domain Name System (DNS)
RFC 1812 Requirements for IPv4 routers
RFC 1918 IP addressing
RFC 2581 TCP congestion control
IPv6 Features
RFC 1981 Path MTU discovery for IPv6
RFC 2460 IPv6 specification
RFC 2464 Transmission of IPv6 packets over Ethernet
networks
RFC 3056 Connection of IPv6 domains via IPv4 clouds
RFC 3484 Default address selection for IPv6
PRODUCT
PORT SPEED
10mbps 100mbps 1gbps 10gbps
AT-x510-28GTX
117µs 14.4µs 4.4µs 3.1µs
AT-x510-52GTX
119µs 16.8µs 6.7µs 4.9µs
AT-x510-28GPX
117µs 14.4µs 4.4µs 3.1µs
AT-x510-52GPX
119µs 16.8µs 6.7µs 4.9µs
Latency (microseconds)
PRODUCT WIDTH DEPTH HEIGHT MOUNTING
WEIGHT
Unpackaged packaged
AT-x510-28GTX
440 mm (17.32 in) 325 mm (12.80 in) 44 mm (1.73 in) Rack-mount 4.3 kg (9.48 lb) 6.3 kg (13.89 lb)
AT-x510-28GPX
440 mm (17.32 in) 400 mm (15.75 in) 44 mm (1.73 in) Rack-mount 5.8 kg (12.79 lb) 7.8 kg (17.20 lb)
AT-x510-28GSX*
440 mm (17.32 in) 325 mm (12.80 in) 44 mm (1.73 in) Rack-mount 4.8 kg (10.58 lb) 6.8 kg (14.99 lb)
AT-x510-52GTX
440 mm (17.32 in) 325 mm (12.80 in) 44 mm (1.73 in) Rack-mount 5.2 kg (11.47 lb) 7.2 kg (15.88 lb)
AT-x510-52GPX
440 mm (17.32 in) 400 mm (15.75 in) 44 mm (1.73 in) Rack-mount 6.2 kg (13.67 lb) 8.2 kg (18.08 lb)
PRODUCT
NO POE LOAD FULL POE+ LOAD
MAX POE
POWER
MAX 15.4W
POE PORTS
MAX 30W
POE+ PORTS
max power
consUmption
max he at
dissipation
noise
max power
consUmption
max he at
dissipation
noise
AT-x510-28GTX
52W 180 BTU/h 45 dBA - - - - - -
AT-x510-28GPX
67W 230 BTU/h 45 dBA 530W 1800 BTU/h 55 dBA 370W 24 12
AT-x510-28GSX*
74W 252 BTU/h 45 dBA - - - - - -
AT-x510-52GTX
86W 290 BTU/h 45 dBA - - - - - -
AT-x510-52GPX
93W 320 BTU/h 45 dBA 550W 1900 BTU/h 55 dBA 370W 24 12
Electrical Approvals and Compliances
» EMC: EN55022 class A, FCC class A, VCCI class
A, ICES-003 class A
» Immunity: EN55024, EN61000-3-levels 2
(Harmonics), and 3 (Flicker) – AC models only
Safety
» Standards: UL60950-1, CAN/CSA-C22.2 No.
60950-1-03, EN60950-1, EN60825-1, AS/NZS
60950.1
» Certification: UL, cUL, TUV
Restrictions on Hazardous Substances (RoHS)
Compliance
» EU RoHS compliant
» China RoHS compliant
Country of Origin
» Singapore
x510 Series | 5

Allied Telesis x510 Series Specifications

General

Series	x510 Series
Category	Switch
Operating Temperature	0°C to 50°C (32°F to 122°F)
MAC Address Table Size	16K entries
VLANs	4094
Jumbo Frames	9KB
Power Supply	Internal power supply, 100-240V AC, 50/60Hz
Stacking	Up to 8 units
Layer	Layer 2
Power over Ethernet (PoE)	Available on some models
Management	Web-based, CLI, SNMP
Security Features	Access Control Lists (ACLs), 802.1X authentication, port security
Weight	Varies by model
Ports	Varies by model (e.g., 24, 48)
Dimensions (W x D x H)	440 x 260 x 44 mm (x510-52GP), 440 x 260 x 44 mm (x510-28GP)
