Allied 4HP14B - FAN BLADE; REFRIGERATION DATA; COOLING PERFORMANCE WITH DTC1

508090-01Issue 2032Page 4 of 40
REFRIGERATION DATA
Model
Factory Refrig.
Charge (Oz.)*
TXV
Refrigerant Line Size
Outdoor Unit
Connection
Indoor Unit
Connection
Suction Liquid Suction Liquid Suction Liquid
4HP14B18P-50 112 H4TXV01 3/4 3/8 3/4 3/8 3/4 3/8
4HP14B24P-50 115 H4TXV01 3/4 3/8 3/4 3/8 3/4 3/8
4HP14B30P-50 115 H4TXV01 3/4 3/8 3/4 3/8 3/4 3/8
4HP14B36P-50 161 H4TXV02 7/8 3/8 7/8 3/8 3/4 3/8
4HP14B42P-50 171 H4TXV02 7/8 3/8 7/8 3/8 7/8 3/8
4HP14B48P-50 171 H4TXV02 7/8 3/8 7/8 3/8 7/8 3/8
4HP14B60P-50 193 H4TXV03 11/8 3/8 7/8 3/8 7/8 3/8
* Factory charged for 15 feet of line set; adjust per installation instructions.
Refrigerant charge also varies with indoor unit; Refer to refrigerant charge label
COOLING PERFORMANCE WITH DTC
1
Outdoor Model
Indoor Model Cooling Heating
Evap. Coil or Air
Handler
3
SEER EER
AHRI Rated
Capacity
2
Sensible
Capacity
HSPF
47° 17°
Btuh COP Btuh COP
4HP14B18P-50 BCE5C18MA4X 14.00 12.00 18000 14200 8.20 17600 3.5 10800 2.3
4HP14B24P-50 BCE5C24MA4X 14.00 12.00 23800 19000 8.20 22200 3.6 14300 2.4
4HP14B30P-50 BCE5C30MA4X 14.00 11.50 29600 23200 8.20 27000 3.5 17500 2.4
4HP14B36P-50 BCE5C36MA4X 14.00 12.00 33400 25800 8.20 31200 3.4 20000 2.4
4HP14B42P-50 BCE5C42MA4X 14.00 12.00 40500 29500 8.20 39500 3.2 26200 2.4
4HP14B48P-50 BCE5C48MA4X 14.00 11.50 47500 36000 8.20 46000 3.3 29000 2.4
4HP14B60P-50 BCE5C60MA4X 14.00 12.00 56500 41500 8.20 54500 3.5 35400 2.6
Note:
1 DTC = Designated Tested Combination
2 Certified in accordance with Unitary Air Conditioner Certification Program, which is based on AHRI Standard 210/240
3 A blower time delay relay is standard on all Allied Air Enterprises furnace and AH products.
FAN BLADE
Model
Diameter
(in.)
# of Blades Pitch Part #
4HP14B18P-50
22 3 20 82W58
4HP14B24P-50
22 3 20 82W58
4HP14B30P-50
22 3 26 43W37
4HP14B36P-50
22 3 28 16L95
4HP14B42P-50
26 4 22 21W10
4HP14B48P-50
26 4 22 21W10
4HP14B60P-50
26 4 22 21W10
