Parts - 7420, 8420 & 8420G Snowblower
When Ordering Parts
Always give your dealer the Model, Color and Serial Number of your machine to assist them in
ordering and obtaining the correct parts. Use the exploded view and tabular listing of the area of
interest to exactly identify the required part.
Item Part Number Description Qty
1 811792 Bolt Hex 0.375 x 1.50 8
2 812363 Nut Lock (Steel) 0.375 Grb Pl 8
3 815263 74" Hitch LHS 1
4 815264 74" Hitch RHS 1
5 81527 Bolt Hex 0.25Nc x 1.00 Gr5 Pl 1
6 81549 Bolt Hex 0.313Nc x 0.75 Gr5 Pl 4
7 81568 5/16" Hex Nut Pl 4
8 81569 5/16" Lock Washer Pl 4
9 81570 Washer 0.375 Flat St Hs Pl 16
10 815900 74" Main Housing Weldment 1
815901 84" Main Housing Weldment 1
815902 84G Main Housing Weldment 1
11 815903 74"/84" Spout Weldment 1
12 815911 74"/84" Spout Spacer 4
13 815912 74"/84" Spout Clamp 4
14 81592 3/8" Hex Nut (Pl) 16
15 81593 Lock Washer 0.375 16
16 816131 3/4" Dia. x 4.25" Lg Clev Pin 2
17 816132 0.50 Dia. x 2.5 Bent Hitch Pin 1
18 816137 74/84 Fan Shaft 1
19 816151 Clevis Pin 0.88" Dia. x 3-3/4" Lg 2
20 816169 74" Driveshaft Weldment 1
816171 84" Driveshaft Weldment 1
965403 84G Driveshaft Weldment 1
21 81620 Bolt Hex 0.500Nc x 1.25 Gr5 Pl 8
22 81636 1/2" Hex Nut (Pl) 8
23 81637 0.50 Lock Washer 8
24 81676 5/8" Hex Nut (Pl) 1
25 81677 Washer Lock 0.625 Pl 1
26 81678 5/8" Flat Washer Std (Pl) 4
27 81700 3/4" Hex Nut (Pl) 3
28 81701 3/4" Lock Washer (Pl) 3
29 84072 3/8" x 3/4" Hex Bolt (Pl) 4
30 84268 Bolt Hex 0.625Nc x 1.50 Gr5 Pl 1
31 84289 5/8" x 3" Hex Bolt (Pl) 1
32 84336 3/4" x 4" Hex Bolt (Pl) 3
