26
Parts - 7420, 8420 & 8420G Snowblower
Item Part Number Description
F844 Long PTO Shaft Complete (Optional)
936285 Tractor Half of PTO (Shear)
936280 Implement Half of PTO (Clamp Yoke)
1 936277 Shear Assembly
2 936199 Safety Slide Lock Repair Kit
(Collar, Spring, Ret. Ring, 2-Pawls)
3 936249 Shear Assembly Repair Kit
(3/8" x 1/2" Bolt, Lube, Blank, 31-1/4" Balls)
4 903296 Shear Bolt - 5/16" x 1" (Grade 5) (Pack of 10)
5 812362 5/16" Lock Nut
6 936025 Repair Kit (Option)
906504 Extended Life Repair Kit (Std)
7 936281 Yoke & Tube
8 936319 Bearing & Snap Ring Kit
9 936282 Inner Shield
10 936283 Outer Shield
11 936284 Yoke & Shaft
12 936269 Clamp Yoke
13 81627 1/2" x 3" Hex Bolt (pl)
14 812364 1/2" Lock Nut (pl)
F9102 Hand Crank Kit
5 Hand Crank
7 965927 3/16" Cable x 100" Long
13 Nut Hex 0.500nc Gr. 2 pl
14 Washer Lock 0.500 pl
72 Bolt Hex 0.500nc x 1.75 Gr. 5 pl
Optional Bundles
