29
Change Fuel Filter
For filter part number, see Replacement Parts.
1. Remove old filter (G) using a filter wrench.
2. Apply a light coating of oil on filter seal (H).
3. Install new filter until seal contacts pump, then
tighten 1 additional turn by hand.
4. After installing filter, check for leaks. Tighten as
necessary.
G
H
Clean Outside Of Radiator / Oil Cooler
Gently clean fin tubes (I) of radiator / oil cooler of dirt
and debris.
NOTICE
Do not use high pressure cleaning equipment, as it
may damage fin tubes.
I
Clean Inside Of Radiator
Contact your authorized dealer.
Grease Trailer Hub Bearing
Contact your authorized dealer.
Change Coolant
WARNING
• Be sure to stop the machine and allow time to cool.
Then loosen the radiator cap one notch. After the
coolant water is sufficiently cooled and the inner
pressure is released, take the cap off.
If this procedure is neglected, the inner pressure
can blow off the cap. Steam jetting out of the
radiator could result in causing scalding. Follow this
procedure under all circumstances.
• LLC (Antifreeze) is a toxic material.
If swallowed, seek immediate medical attention. Do
not induce vomiting.
If in eyes, wash eyes with clean running water and
seek immediate medical attention.
When storing, store in an approved container,
clearly labeled ‘LLC (Antifreeze) inside’, away from
children.
• Keep away from fire and flame.
1. To drain coolant, remove radiator cap (A). Remove
operation side radiator drain plug (B) and open
drain valve (C, engine side) for drainage.
2. After draining, close drain valve and replace drain
plug, then supply coolant through filler port (A).
(Coolant capacity: approx. 1.93 gal (7.3L).)
3. After filling with coolant, run machine in unloaded
condition for approximately 2 to 3 minutes. Stop
machine and check coolant level. Add as needed.
To Next Page
