27
Length - Outriggers
Deployed
14 ft - 2 in 4,32 m
Width - Towing
Transport
6 ft - 5 in 1,96 m
Width - Outriggers
Deployed
12 ft - 7 in 3,84 m
Height - Towing
Transport
8 ft - 5 in 2,57 m
Height - 4 Metal Halide
Lights Tower Fully
Elevated
25 ft - 4 in 7,71 m
Height - 4 LED Lights
Tower Fully Elevated
24 ft - 4 in 7,42 m
Height - 4 Metal Halide
Lights Tower Fully
Elevated
26 ft - 5 in 8,05 m
Height - 6 LED Lights
Tower Fully Elevated
25 ft - 5 in 7,75 m
Bottom Clearance 8.5 in 216 mm
Shipping Weight * 3685 lbs 1672 kg
Gross Vehicle Weight
Rating (GVWR)
5000 lbs 2268 kg
* Shipping weight varies by model
Trailer
Specification Imperial Metric
Gross Axle Weight
Rating (GAWR)
5000 lbs 2268 kg
Tire Size and Rating ST225/75R15D Load Range 'D'
Rims 15 x 6 JJ
Cold Tire Inflation
Pressure
65 psi 448 kPa
Max. On-Road Speed 65 mph 105 km/h
Max Off-Road Speed 20 mph 32 km/h
Fuel Tank 100 US Gallons 378 L
Frame Structure Formed welded steel design
Axle Tubular design
Hubs (6) 1/2-20 UNF studs on a 5.5 inch (139,7 mm)
bolt circle
Springs Elliptical springs - 3 Leafs
Trailer Road Lighting Stop, turn, tail, side markers, illuminated license
plate bracket
Trailer Road Light
Connector
7-Way RV Connector
Lifting Eye - Rated
Capacity
5000 lbs 2268 kg
Tie-Down Points 2 tie-down slots in rear forklift pocket tube, and 2
tie-down slots at front forklift pocket tube
Forklift Pockets 2 each side
Outrigger and
Stabilization System
Left and right side outriggers with adjustable
screw type jacks, 1 adjustable screw type tongue
jack
Maximum Wind Speed
- Tower Elevated
and Outriggers and
Stabilizers Deployed
53 mph
85 km/h
Electrical - AC Power
Frequency 60 Hz
Rated Prime Power Output with
Kubota D1105 Engine
8.0 kW
Rated Prime Power Output with Cat
1.1 ESI Engine
8.0 kW
Rated Prime Power Output with Cat
1.5T Engine
15.0 kW
Rated Prime Power Output with
Isuzu 4LE2T Engine
20.0 kW
Alternator 120 / 240 VAC capacitor regulated
120 / 240 VAC Automatic Voltage
Regulator (AVR)
Phases 1-phase
3-phase
Automatic Lighting - Sequenced
Lighting System (SLS)
Automatically turns lights on after
engine start and delays engine
shutdown to turn off lights first to
prevent generator from shutting
down under load.
Note: Not available with generator
disconnect.
Light Tower
Structure Six-section tubular steel design
Actuation Standard - Hydraulic
Guide Pads Polyethylene self-lubricating
Light Fixtures
Metal Halide – Standard
Power Consumption – per Fixture 1250 W
Lumens - per Fixture 135,500
Warm-Up Time 2 - 4 minutes
Re-Start Time 10 - 15 minutes
Bulb Shape BT37
Base Mogul (E39)
LED – Optional
Color Temperature 5000° K
Power Consumption – per Fixture 320 W
Lumens - per Fixture 38,500
Lamp Ballast (Metal Halide)
Capacitor
Nominal Voltage 525 VAC
Capacitance 28 μf
Transformer
Input Voltage 120 / 220 / 240 VAC
Frequency 60Hz
Line Current 9.3 / 5.0 / 4.5 A
Engine - General Service Information
Kubota D1105
Specification Imperial Metric
Model Kubota D1105
Type Water-cooled 3-cylinder diesel
Displacement 68.5 cu. in. 1100 cc
Aspiration Naturally aspirated
Emissions EPA Tier 4 Final / EU Stage IV
Power Output - Prime 13.6 Hp @ 1800 rpm 11,5 kWm @ 1800 rpm
