Compatible from firmware version BIOS2BT02
5.2 Advanced settings of the wings stroke (parameter = )
Press and keep pressed the buttons UP[+] e MENU
for at least 5 seconds.
The wing 1 moves in opening.
If the wing moves in closing press the button
DOWN to stop and reverse the direction of
movement and give a step by step command
(SS) to resume the procedure
Unlock the motors, move the wings in the middle of the
stroke and relock the motors.
Connect to the MOTOR 1 output the wing which beats.Install an aventual electrical lock on this wing. MOTOR 1 is always activated first during opening
phase and in second during closing phase. In this procedure it is necessary to provide also the positions where the slowing downs begin with a step by
step command (SS).
When the wing 1 reaches the opening mechanical
stop give a step by step command (SS)
The wing 1 stops and the wing 2 moves in
opening.
If the wing moves in closing press the button
DOWN to stop and reverse the direction of
movement and give a step by step command
(SS) to resume the procedure
When the wing 2 reaches the opening mechanical stop
give a step by step command (SS)
Wing 2 stops, after 2 seconds the wing 2 moves
in closing
When the wing 2 reaches the closing mechanical stop
give a step by step command (SS)
Wing 2 stops, after 2 seconds the wing 1 moves
in closing
When the wing 1 reaches the closing mechanical stop
give a step by step command (SS)
Wing 1 stops, after 2 seconds the wing 1 moves
in opening
When the wing 1 reaches the the opening mechanical
stop give a step by step command (SS)
Wing 1 stops, after 2 seconds the wing 2 moves
in opening
When the wing 2 reaches the the opening mechanical
stop give a step by step command (SS)
Wing 2 stops, the gate closes with the slowing
downs set during the learning phase and the
delay between the wings set in the menu. When
the gate is closed the learning phase is ended.
When the wing 2 reaches the desired position of
beginning of slowing down give a step by step
command (SS)
The wing 2 begins the slowing down
When the wing 1 reaches the desired position of
beginning of slowing down give a step by step
command (SS)
The wing 1 begins the slowing down
When the wing 1 reaches the desired position of
beginning of slowing down give a step by step
command (SS)
The wing 1 begins the slowing down
When the wing 2 reaches the desired position of
beginning of slowing down give a step by step
command (SS)
The wing 2 begins the slowing down
1
2
3
4
5
6
7
8
9
10
11
12
For a correct functioning of the system, it is absolutely indispensable the use of mechanical stops in opening and closing.
Warning: in case of intervention of a safety device, the learning is stopped and will appear on the display the written
Press Step by Step key to start again the learning from the 2
nd
point.
