6 / 12
6-1622189 rev.1 22/05/2015
Compatible from firmware version BIOS2BT02
6.1 Base settings menu:
MENU DESCRIPTION
SELECTABLE
VALUES
min-max
DEFAULT UNITS
Auto reclosing time (0 = disabled) 0-900 20 s
Auto reclosing time after transit(0 = disabled) 0-30 0 s
Obstacle sensitivity (0 = disabled 100 = maximum sensitivity) 0-100 0 %
Slowing down mode
0 = normal
1 = fast with more torque
0-1
0
Motor torque (running torque) 10-100 100 %
Anti slip 0-300 0 s
Second wing delay 0-300 2 s
Soft start
0 = disabled
1 = enabled
0-1 0
Amplitude of slowing down (0 = disabled)
P = personalized during learning
0…100% = percentage of stroke
0-100 15 %
After black-out
0 = no action
1 = closing
0-1 0
Step by step configuration
0 = normal (OP-ST-CL-ST-OP-ST…)
1 = alternated STOP (OP-ST-CL-OP-ST-CL…)
2 = alternated (OP-CL-OP-CL…)
3 = condominium – timer
4 = condominium with immediate auto reclosing
0-
4 0
Number of motors
1 = 1 motor
2 = 2 motors
1-2 2
6. Menu
Entering the menu:
To enter the base menu settings keep pressed the MENU button for at least one second
To enter the advanced menu settings keep pressed the MENU button for at least five seconds
Navigation into the menu:
It is possible to move from an entry to another one using UP[+] e DOWN[-] buttons,
To change a parameter keep pressed the MENU button for at least 1 second until the parameter begins blinking,
so release the key.
Use UP[+] and DOWN[-] buttons to change the parameter
At the end keep pressed MENU for al least 1 second until the parameter stops blinking to save the change.
A quick pressure of the menu key is enough to leave a menu
Ex. Base menu
Ex. Advanced menu
6.2 Advanced menu:
MENU DESCRIPTION
SELECTABLE
VALUES
min-max
DEFAULT UNITS
First coupling between Bluetooth device and control unit
..
Electrical brake activation time
0 = disabled
1 - 100= enabled
0-100 0 x0.01 s
..
Functioning of closing photocell PHOTO1 moving from closed
0 = Check PHOTO1
1 = The gate opens also with PHOTO1 busy
0-1 1
