Top Panel
LABEL STATE DESCRIPTION
LED RRSI
3 BARS Connected 95% and above RSSI (Excellent)
2 BARS Connected 55-94% RSSI (Recommended)
1 BAR Connected 10-54% RSSI (Weak)
LABEL DESCRIPTION
WPS
BUTTON
Connect ALL0237R to any WPS capable devices
WPS
Button
