DIP (SW1) FUNCTIONS DEEPENING
- DIP 3 ON : “PRESSED BUTTON” FUNCTION ACTIVATED
OPENING ORDER = OPENING WITH PRESSED BUTTON
CLOSING ORDER = CLOSING WITH PRESSED BUTTON (with close pressed an order of “open”
blocks the closing movement)
THE PEDESTRIAN ORDER IS NOT CONNECTED
DYNAMIC ORDER = OPENING WITH SELF-HOLDING AND CLOSING WITH PRESSED BUTTON
At end opening, an impulse to the dynamic order closes with pressed button (closing activated, the order release
for 3 sec. (before arrive at FCC) stops the function = an other impulse connects the opening.
OPEN END-RUN = STOP THE OPENING
CLOSE END-RUN = STOP THE CLOSING
BLOCK = BLOCK THE MOVEMENT
With DIP8 on ON; “A” HIGH PHOTOCELL = PHOTOCELL BLOCKS IN OPENING
With DIP7 on ON; “B” LOW PHOTOCELL = PHOTOCELL BLOCKS IN CLOSING
With DIP6 on ON; DW24B (edges) = DW24B BLOCKS IN CLOSING
With DIP8 on OFF; “A” HIGH PHOTOCELL = PHOTOCELL NOT CONNECTED (OR DISACTIVATED)
With DIP7 on OFF; “B” LOW PHOTOCELL = PHOTOCELL NOT CONNECTED
With DIP6 on OFF; DW24B (edges) = DW24B NOT CONNECTED
- DIP3 OFF : PRESSED BUTTON DISACTIVATED
AUTOMATIC OR SEMIAUTOMATIC CYCLE
- DIP1 ON : “LOW” PHOTOCELL STOP TEMPORARILY THE MOUVEMENT
(stop the movement until the “low” photocell is obscurated, keep the counter of the
“Work Time”).
ON : “HIGH” PHOTOCELL BLOCK THE MOUVEMENT (CENTRALE BLOCKED)
ON REQUEST
TOUCH METER :
The electronic “counter” increase of 1 unit the count of manoeuvres made from the door every times that
the opening end-run is pressed.
Increase the count also when the open buttom is pressed and then the door is blocked with the mushroom
before being stopped from the end-run of open.
