ALLTRONIC Micro7 - Regulation Times with Dip Switch SW2; Working Time Settings; Pause Time Settings; Pedestrian Time Settings

Regulatin Times (Dip Swich SW2)
WORKING TIME:
Dip 1 OFF min. 27 sec. MAX 50 sec.
Dip 2 OFF
Dip 1 OFF min. 80 sec. MAX 150 sec.
Dip 2 ON
Dip 1 ON min. 04 sec. MAX 30 sec. (set of factor)
Dip 2 OFF
Dip 1 ON min. 04 sec. MAX 150 sec.
Dip 2 ON
PAUSE TIME:
min 01 sec. MAX 70 sec. (set of factor)
With R11 shunt the max time is 200 sec.
PEDESTRIAN TIME:
min. 02 sec. MAX 13 sec.
REVERSAL TIME:
Dip 3 OFF reversal time = 0,5 sec.
Dip 4 OFF
Dip 3 OFF reversal time = 1 sec. (set of factor)
Dip 4 ON
Dip 3 ON reversal time = 2 sec.
Dip 4 OFF
Dip 3 ON reversal time = 4 sec.
Dip 4 ON
SHUNTS SET
W3 - W4 – W5 – W6 – W7 = For predisposition type of Rx Radio (on costumer request)
W8 Shunted: DW control not connected
Free: DW control connected (insert DW24 in J3 position)
W1 Shunted 1-2 (central – left) CH2 of receiver FOR PEDESTRIAN ORDER
Shunted 2-3 (central – right) CH2 of receiver FOR CLOSE ORDER
W2 Shunted 4-5 (central – left) CH1 of receiver FOR DYNAMIC ORDER
Shunted 5-6 (central – right) CH1 of receiver FOR OPEN ORDER
