Allworx Connect 324 - Rear Chassis Views

Allworx
®
Connect™ Server Family Installation Guide
866.ALLWORX * +1 585 421 3850 Page 7
www.allworx.com
Version: F Revised: June 21, 2018
2.2.5 Connect 320 Server
2.3 Rear Chassis Views
The following views indicate the features available on the rear of each Connect server. The Page and
Door contacts are:
2.3.1 Connect 731 Server
2.3.2 Connect 500 Series Server
NO Normally Open
COM Common
NC Normally Closed
Power
Button
Activity
Light
Console Serial
Connector
USB
Connector
Gigabit
Ethernet
Ports
Line Input
Jack and Output
Inside Extension
Phone Port
Rear Terminal Connector
Power Cord Connector
Protective Earthing Terminal
Rear Terminal Connector
Power Supply Connector
Protective Earthing Terminal
