Allworx Connect 324 - Rack Mounting

Allworx
®
Connect™ Server Family Installation Guide
Page 10 866.ALLWORX * +1 585 421 3850
www.allworx.com
Version: F Revised: June 21, 2018
To install the Connect server on a tabletop or shelf:
1. Remove the four rubber feet from the packaging and turn the chassis over.
2. Remove the paper backing from one rubber foot and place it at a corner on the bottom of the
chassis.
3. Repeat for the remaining three rubber feet in the remaining three corners of the chassis.
3.2 Rack Mount
The table below indicates a list of all equipment and requirements necessary to rack mount the
Connect server.
To mount the Connect server:
1. Verify the clearance around the Connect server front and rear panels for the power, network,
and telephony connections.
2. Align a rack ear on the side of the Connect server so that:
• the four holes of the rack ear align with the four holes on the side of the Connect server.
• the perpendicular side of the rack ear faces outward from the front of the Connect server
to mount into the rack.
3. Secure to the Connect server chassis using four 6-32 flat head screws. Repeat for the opposite
side of the Connect server.
4. Follow the
“Power Connection” on page 14 instructions.
5. Install the Connect server into the rack using appropriate hardware.
Equipment Qty Requirements
Rack
1
1U high rack mount standard 19” rack
Rack Mount Kit
1
Includes:
• Two rack ears
• Eight 6-32 flat head screws
