Figure 2 R30 Install options
Must make sure there is no large area cove
r, high voltage cable,
5
transformer, etc. when installation satellite antenna. It is for avoid
interference satellite antenna signal.
It is not suggested to move antenna or change internet port after
configuration. Please reference “Appendix-2” to make sure device output
right signal if the position of antenna or internet port has been changed.
After install R30 and set antenna in right position, connect R30 to laptop
and start configuration. The way of cable installation show in below.
（Figure3）
Internet Port
Power
Supply
Antenna
Cable
To Next Page
