T1 - Omron Control INSTRUCTION MANUAL Page 12
SHAW-ALMEX INDUSTRIES LIMITED 49900-030 October 2000
Revised Mar03, Jun04, Aug04, Jun05
7.4. Vulcanizer Over Heating
FAULT CORRECTION
1. Temperature set improperly. 1. Ensure that controller set point is correct.
2. Faulty temperature controller. 2. Refer to OMRON instruction manual.
3. Faulty relay.
3.
Disconnect power supply, and remove control panel
cover. Remove the connectors from the power relay
check for continuity between relay terminals 2-4 or 6-8. If
there is continuity, relay must be replaced.
4. Faulty RTD temperature sensor. 4. Measure the resistance between pins 4-5 and 4-6 on the
platen receptacle. Depending on the platen temperature,
the resistance should be between 100-170 Ohms.
7.5. Controller will not maintain Set Point Temperature
FAULT CORRECTION
1. Controller not calibrated
properly.
1. Follow calibration procedure.
2. Faulty temperature controller. 2. Refer to OMRON instruction manual. Replace
temperature controller
8. Service
8.1. Emergency Service
Contact: Service Department
Telephone: 705 746 5884
1 800 461 4351 (Canada and U.S. only)
Fax: 705 746 9484
Mail: SHAW-ALMEX INDUSTRIES LIMITED
P.O. Box 430
Parry Sound, Ontario
Canada, P2A 2X4
E-mail: service@almex.com
8.2. Return of Goods Authorization
The service department of Shaw-Almex Industries Limited MUST be contacted for the necessary authorization
and documentation prior to returning goods to the factory.
The service department may be reached at the above numbers.
8.3. Guarantee
Your ALMEX vulcanizer is guaranteed against defective parts, material and workmanship for a period of 12
months from the date of purchase. For complete details, refer to the Warranty Card.
