Chapter 2. Unpacking and Hood Set Up
This chapter describes unpacking and setting up (preparing) the ABT Balometer
®
capture hood for use.
Unpacking
As you unpack the instrument and accessories, check the components against your packing list. If any parts
are missing or damaged, notify us immediately. Table 1 lists available standard and optional components.
The ABT Models ship with the hood and frame attached to the instrument base and must be removed from the
case as a set before the instrument base can be lifted out. Caution must be exercised to assure that the pieces
do not separate, since dropping the instrument may damage the instrument.
Table 1: List of Standard and Optional Components
Item
Part No.
Model ABT701—30 to 1000 CFM with 2 ft × 2 ft (610 mm × 610 mm) hood
ABT701
Model ABT711—50 to 2000 CMH with 2 ft × 2 ft (610 mm × 610 mm) hood
ABT711
Model ABT703—30 to 1000 CFM with 16 in × 16 in (406 mm × 406 mm) hood
ABT703
Model ABT713—50 to 2000 CMH with 16 in × 16 in (406 mm × 406 mm) hood
ABT713
Wheeled Carrying case
1319379
AA-size alkaline battery, four required
1208013
Operation and Service Manual
6002462
Center handle
534593173
1 ft × 4 ft (305 mm × 1220 mm) and 2 ft × 4 ft (610 mm × 1220 mm) fabric hood and
frame kit
801206
1 ft × 5 ft (305 mm × 1525 mm) and 3 ft × 3 ft (915 mm × 915 mm) fabric hood and
frame kit
801207
1 ft × 4 ft (305 mm × 1220 mm) fabric hood and frame kit
801200
2 ft × 4 ft (610 mm × 1220 mm) fabric hood and frame kit
801201
1 ft × 5 ft (305 mm × 1525 mm) fabric hood and frame kit
801202
2 ft × 2 ft (610 mm × 610 mm) fabric hood and frame kit
801097
16 in × 16 in (406 mm × 406 mm) hood and frame kit
801209
Please register your ABT Balometer
®
capture hood online at http://register.tsi.com. Registering your product will
allow us to inform you of product updates.
9
