7
Rapid CT set-up
– When the CT value is not known and only used at the moment of the installation, the P.01 parameter for CT primary can remain set at OFF while all the others
can be programmed.
– In this case, during the system installation and once the controller is powered up, the display will show a ashing CT (Current Transformer). By pressing ▲ ▼
the CT primary can be set directly.
Once programmed, press MAN/AUT to conrm. The unit will store the setting into P.01, and directly restart in automatic mode
Parameter table
– Below are listed all the programming parameters in tabular form. For each parameter are indicated the possible setting range and factory default, as well
as a brief explanation of the function of the parameter. The description of the parameter shown on the display can in some cases be dierent from what is
reported in the table because of the reduced number of characters available. The parameter code can be used however as a reference.
Note: The parameters shown in the table with a shaded background are essential to the operation of the system, thus they represent the minimum
programming required for operation.
BASE MENU
Cod Description ACC UoM DEF RANGE
P.01 CT primary Usr A OFF OFF / 1...10.000
P.02 CT secondary Usr A 5 1 / 5
P.03 CT read phase Usr L1 L1
L2
L3
P.04 CT wiring polarity Usr Aut Aut
Dir
Rev
P.05 Voltage read phase Usr L2-L3 L1-L2
L2-L3
L3-L1
L1-N
L2-N
L3-N
P.06 Smallest step power Usr Kvar 1.00 0.10 ... 10000
P.07 Rated capacitor voltage Usr V 410V 50 ... 50000
P.08 Nominal frequency Usr Hz Aut Aut
50Hz
60Hz
Var
P.09 Reconnection time Adv s 180 1 … 30000
P.10 Sensitivity Usr s 30 1 … 1000
P.11 Step 1 function Usr OFF OFF
1…32
ON
NOA
NCA
FAN
A01…A13
P.12 Step 2 function Usr OFF =
P.13 Step 3 function Usr OFF =
P.14 Step 4 function Usr OFF =
P.15 Step 5 function Usr OFF =
P.16 Step 6 function Usr OFF =
P.17 Step 7 function Usr OFF =
P.19 Cos-phi setpoint Usr 0.96
IND
0.50 Ind – 0.50 Cap
P.20 Alarm messages language Usr ENG ENG
ITA
FRA
SPA
POR
DEU
