Alpha Technologies 1000 Operator's Manual

5 1 Introduction
Alpha Technologies
1.3 The Pinnacle Plus Series
1.3.1 Front Panel
These drawings are used for illustrative purposes only. See your unit for the exact location and
type of all switches and controls. The batteries are reached through this panel.
The control panel’s operation is described in Section 3.2.
Tower Mount
ON-LINEON ON-BATT BYPASS FAULT
ON/OFFFUNC ENTER
Cooling Vents
(Must not be blocked)
Control Panel
Rack Mount
ON-LINEON ON-BATT BYPASS FAULT
ON/O FF
FUNC ENTER
Cooling Vents
(Must not be blocked)
Control Panel
Removable Battery Cover
