Alpha Technologies 1000 - UPS Position; Tower Mount (Stand Alone)

0170009-J0 Rev B
8
A3
S1
S1
A2
3.5 UPS Position
The UPS can be installed in two different orientations: tower mount (stand alone) or rack mount.
To install the UPS as a tower, see the next section. For rack mount, see Section 3.5.3.
3.5.1 Tower Mount (Stand Alone)
Ste p 1
See Section 3.6 to rotate the LCD display to match the physical orientation of the unit.
Ste p 2
NOTE:
