4. Troubleshooting
If your ATS is not working normally, use the following status and
troubleshooting table to make the appropriate adjustments. Please contact your
distributor as soon as possible if the issue cannot be resolved.
Issue Possible reason Solution
ATS is OFF
Not connected to the
electrical grid
Check the connection from the
electrical grid to the ATS input
Abnormal electrical grid Request service by professional
electrician
Input breaker has been
tripped
Reset breaker
Internal components
have been damaged
Please contact the distributor
Power is supplied to
the load but panel
remains off
Internal components
have been damaged
Please contact the distributor
Error code Er01, Er02
Not connected to the
electrical grid
Check the connection from the
electrical grid to the ATS input
Abnormal electrical grid Request service by professional
electrician
Error code Er03 to
Er15
Abnormal power system
Request service by professional
electrician
Error code Er16 Overload Check the load capacity
Error code Er17 to
Er32
Abnormal internal
components
Please contact the distributor
13
5. System Specifications
Model ATS-120 ATS-130
Input
Input voltage
100/110/115/120/127
(+/-5%/10%/15%/20%)
Input voltage range
75Vac~150Vac
Input frequency 50/60Hz(+/- 5%/10%/15%/20%)
Input current 20A 30A
Output
Output voltage 100/110/115/120/127
Output current 20A 30A
Connection
Input NEMA 5-20 x 2 NEMA L5-30 x 2
output NEMA 5-20 x 8
NEMA 5-20 x 8,
NEMA L5-30 x 1
Protection
Input Breaker(option)
Electronic circuit
Communication
RS-232, USB, Dry contact
external slot for option card(SNMP, RS-485)
Transfer time(ms) 8~12ms (Typical)
Efficiency 99%(with full linear load)
Display LCD+LED
Physical
Dimension,
D X W X H (mm)
275x440x44 275x440x88
Net Weight (kgs) 4 6
Environment
Operating
temperature
-5~40C @ 20~90% RH(non-condensing)
Standards
compliance
Safety UL 60950-1/CAN/CSA C22.2 No. 60950-1
EMC FCC Part 15
