150Vac~300Vac
Input frequency 50/60Hz(+/- 5%/10%/15%/20%)
Input current 16A 32A
Output
Output voltage 200/208/220/230/240
Output current 16A 32A
Connection
Input IEC-C20 inlets x2 40A terminal 6P
output
IEC-C13 x 8,
IEC-C19 x 1
IEC-C13 x16,
IEC-C19 x2
Protection
Input Breaker(option)
Electronic circuit
Communication
RS-232, USB, Dry contact
external slot for option card(SNMP, RS-485)
Transfer time(ms) 8~12ms (Typical)
Efficiency 99%(with full linear load)
Display LCD+LED
Physical
Dimension,
D X W X H (mm)
275x440x44 275x440x88
Net Weight (kgs) 4 6
Environment
Operating
Safety UL 60950-1/ CAN/CSA C22.2 No. 60950-1 / IEC 60950-1
EMC FCC Part 15 / EN62310-2
15
6. Appendix A. Dry contacts available for configuration
Event Code
1 Source A no power Er01
2 Source B no power Er02
3 Source A voltage abnormal Er03
4 Source B voltage abnormal Er04
5 Source A frequency abnormal Er05
6 Source B frequency abnormal Er06
7 Source A voltage and frequency abnormal Er07
8 Source B voltage and frequency abnormal Er08
9 ATS no output due to source A and B abnormal Er09
10 Source A voltage unbalance Er10
11 Source B voltage unbalance Er11
12 ATS output voltage unbalance Er12
13 ATS output voltage abnormal Er13
14 ATS output frequency abnormal Er14
15 ATS output voltage and frequency abnormal Er15
16 ATS output overload and cut output Er16
17 ATS output short circuit and cut output Er17
18 Input relay defect on source A Er18
19 Input relay defect on source B Er19
20 Source transfer relay defect Er20
21 ATS output relay defect Er21
22 Internal working power 12V defect on source A Er22
23 Internal working power 12V defect on source B Er23
24 System over temperature Er24
25 System DC offset error Er25
26 EEPROM working abnormal Er26
27 Emergency Power Off Er27
28 Loss LCD connection Er28
29 Internal transferring inhibition by some reason Er29
30 Overload transferring is over 4 times and system lock Er30
31 Inhibit to transferring due to phase angle over shift Er31
32 System Alarm Er32
