ALPHA SPORTS 1-800-922-9024
11
STRINGING THE FRAME
To set the tension, there are two
adjustments. The first adjustment is
to move the marker to the nearest
hash mark of the desired tension.
The hash marks on the scale
are in three-pound increments. The
second adjustment is to fine tune
the tension with the hash marks
located on the knob’s collar. The
hash marks on the collar are in one-
pound increments. For example, to set the tension at 62
lbs, turn the knob so that the marker matches the 60
lbs hash mark on the scale. The 0 hash mark should
be lined up with the platform’s hash mark. Next, turn the
collar two one-pound increments. The 2 lb hash mark
should now be aligned with the platform’s hash mark.
Your tension setting is now 62 lbs. NOTE: When the
machine is not in use, release the tension on the spring
by setting the tension back down to 9 lbs.
