CLAMP BASE ADJUSTMENT
Locate the black cap
on the backside of
the yellow base.
Carefully pull it off.
Turn the swivel base so
that the outer port is
aligned with the inner
port. Take the 3mm
allen key and insert into
the internal adjustment
screw. Turn clockwise
to increase tension. The
ideal locking position for
the lever should be down the center of the swivel
base.
