HORIZONTAL FLUE OPTIONS
Lmax = 12 metres (L/H side X = 185 mm, R/H side X = 425 mm)
L = B + C + E + X
Alpha CD50 - General Boiler Information
L = B + C + X
L = B + E + F + X + (90° bend = 1.3 metre)
L = B + C + X + (2 x 45° bends = 1.8 metre)
Fig. 3
E
C
B
B
C
C
B
E
B
F
VERTICAL FLUE OPTIONS
H
max = 15 metres Hmax = 13.2 metres
Not less than
300 mm
H
Not less than
300 mm
Not less than
300 mm
H
Not less than
300 mm
