EXPANDING LOOP USING THE GPX EISWOLF
1. Switch off the PC
2. Insert new component
3. Integrating components into the circuit
→ Make sure that the outlet of one component is connected to the inlet of the next
component as shown in the image below.
→ Note: When expanding the circuit with components without quick-release fasteners, you
must drain all the coolant first.
4. Top up the coolant
→ You must remove the air from the loop. To do this rock the PC case slightly back and
forth gently. Repeat this until no more fluid will fit into the loop and all air bubbles have
dissapeared.
Mounting example with the Eiswolf GPX
Connect the quick-release connectors as shown.
