Program Sensor
1. To advance the tape to the beginning of the next musical track, press and release the
P.S. UP button @. The display will show “P.S. UP + 1” as shown below. Successive
pressing of this button will increase the number of tracks to be skipped as the tape
advances. The number in the display will increase accordingly. For example, to go from
track 1 to track 4, press the P.S. UP button @ three times (the number in the display
will be “+3"). The tape deck searches for blank sections between tracks to the
beginning of track 4 and begins playback.
2. To access the beginning of the current musical track, press and release the P.S. DN
button @. The display will show “P.S. ON —1*. Successive pressing of this button will
increase the number of tracks to be skipped as the tape rewinds. The number in the
display will increase (in the negative direction) accordingly. For example, to go from
track 5 to track 4, press the P.S. DN button @ twice (the number in the display will be
“—2" as shown below). The tape deck searches for blank sections between tracks to
the beginning of the track 4 and begins playback.
[Example]
P.S. DOWN
P.S. UP
+1 -2
NOTE:
The P.S. cannot detect blank sections of less than 3 seconds.
Auto Reverse
When the tape is played or fast-forwarded to the end, the tape transport automatically
reverses the tape direction and playback begins.
Manual Reverse
To manually change playback direction (switch between side A and side B), press the
PROG button @.
REPEAT
1. Insert the cassette tape and begin playback.
2. When you find a selection you would like to repeat, press the REPEAT button @ until
the RPT indicator appear in the display. This selection will be continuously repeated
until the REPEAT function is disengaged.
3. To cancel the repeat function, press the REPEAT button @ again. The RPT indicator 40
will disappear.
SCAN
1. Press the SCAN button @ and the deck will play the first 10 seconds of each
selection. This feature is convenient when searching for a particular selection on a
tape.
2. Once you have located your desired selection, press the SCAN button @ again to
defeat this function.
Blank SKIP
1. Press the B. SKIP button @ during playback to skip over any blank sections of tape
lasting 15 seconds or more.
2. To cancel the Blank Skip function, press the B. SKIP button @ again.
Return EJECT
1. Insert the cassette tape and begin playback.
2. Press the R. EJECT button @ during one of the following modes and the cassette tape
will automatically eject when:
e Playback mode; After both sides A and B have been played.
e fast Forward mode; After the other side has been played.
The R. EJ indicator @ on that button will light.
3. To cancel the Return Eject mode, press the R. EJECT button @ again.
ee ee
OPERATION
Tape Running Status Display
The dot matrix display @ indicates tape running status. To turn off the display, push the
D. DISP switch @ for more than 2 seconds.
Head Cleaning
When playback sound quality begins to deteriorate, it is time to clean the tape head.
Insert a special head cleaning cassette into the tape deck and allow it to run for
approximately 1 minute to remove any foreign matter. There are special cleaning
cassettes that also clean the capstans and pinch rollers. Please contact your authorized
Alpine dealer for information about these cleaning devices.
@ CD OPERATION
The following instructions apply only to systems that incorporate the Alpine CD Shuttle
with 7619R.
Turn the unit on and access the CD mode by pressing the DISC ( /IN) button @.
Initial System Turn-On
When operating the system for the first time after installation or after the vehicle's
battery has been disconnected and reconnected, press the Reset switch @ with a sharp
pencil or other pointed object.
Disc Check
When the magazine is loaded into the CD Shuttle under playback status with the DISC
( B/I1) button @ pushed, a Disc check for the magazine is carried out.
“DISC CHK” on the dot matrix display @ is blinking during the check, and then the
player enters the pause mode after completion of the check.
Normal Play
1. Press the DISC { »/EE) button 0.
2. The first disc will begin playback.
3. After the last track on the last disc is played back, the pickup will return to the
beginning of the first track of the first disc and begin playback from that point.
Pause
While the disc is playing, press the DISC ( ®/If ) button &@ to temporarily stop playback.
The dot matrix display @ will show “PAUSE”. To resume playback, press the DISC button
( P/IL) ® again.
Music Sensor (Skip)
This feature allows you to access the beginning of your musical track selection simply,
and quickly. It is functional in the play or pause mode. The Track No. indicator 4% shows
the track number you have selected.
e To advance to the next track on the disc, press the UP/FF switch 3.
1. Playback stops, and the pickup moves up to the beginning of the next track. That
track number appears in the Track No. indicator 47.
2. Playback begins immediately.
3. If you wish to access a track further ahead on the disc, continue pressing and
releasing the UP/FF switch @ until you reach the track of your choice.
e To replay the track that is currently playing, press and release the DN/REW switch
5
1. Playback stops, and the pickup moves back to the beginning of the current track
The track number in the Track No. indicator 47 remains the same.
Playback begins immediately from the beginning of the track
3. If you access a track further towards the beginning of the disc, continue pressing
and releasing the DN/REW switch 435 until you reach the track of your choice.
Nm
| OPERATION
Direct Disc Access
1. Press one of the Direct Disc Access buttons (@ — 2) to select from discs 1 — 6. The
disc and track numbers wil! appear in the display.
2. Press the UP/FF @ or DN/REW 8 switch for musical track selection.
Fast Forward/Fast Backward
The fast forward/fast backward feature works in the play mode only.
Press either the FF @ or the REW @ switch and hold it down for more than 1 second.
To move the pickup forward rapidly, hold down the FF switch @.
To move the pickup backward rapidly, hold down the REW switch @9.
Release the button when you get to the desired position on the disc.
When the pickup reaches the end of the disc, it will begin playback from the beginning
of the first track on the next disc.
aAPWN>
REPEAT (One/All)
This feature allows you to continuously repeat a single track or one entire disc.
To Repeat a Single Track
1. Locate the music track of your choice using the UP @ or DN & switch.
2. Press the REPEAT button @.
The RPT indicator @ will illuminate, and “RPT ONE” indicator on the dot matrix display
® will appear.
The music track will be played back repeatedly.
3. To stop repeat play, press the REPEAT button twice. The "RPT OFF” indication on the
dot matrix display @ will appear.
To Repeat an Entire Disc
1. While playing a disc, press the REPEAT button @ until the RPT @ and ALL ®
indicators will illuminate.
2. The disc will be played back repeatedly.
3. To stop repeat play, press “he REPEAT button @ once. The indicator illumination will
be off.
Disc Scan
Press the SCAN button @ and the unit will playback the first 10 seconds of each track
in succession. This function is useful in searching ahead on a disc for a specific selection.
Pressing the SCAN button @ a second time deactivates the function.
M.L.X. (Random Play)
Press the M.LX. button @D while the unit is in the play or pause mode. Musical tracks on
the selected disc will be played back in a random sequence generated by the
microprocessor. After all the tracks on the disc have been played back once, the player
will begin a new random sequence.
Q.R.B. Minder
This unit is equipped with a built-in theft prevention reminder system. If the unit is not
removed from the Quick Relezse Bracket after turning the ignition key off, a beeper will
sound as a reminder to remove the unit.
Whether the ignition is on or off, the unit may beep when it is being removed from the
dash.
You can switch the Q.R.B. Minder system on or off by the following.
1. Press the TUNE switch @ for 3 seconds.
2. Press the Preset No. 4 button @ to switch the display between “QRBM ON” and
“QRBM OFF”
QRBM ON : Q.R.B. Minder is on.
QRBM OFF | : ORB. Minder is off.
NOTE:
The
unit
is
initially
set
with
the
Q.R.B.
Minder
system
on.
If
the
vehicle’s
engine
does
not
start
for
over
2
seconds
after
turning
the
ignition
key
on,
the
Q.R.B.
Minder
system
may
be
triggered.
